Mobile vacuum system
MVS 20/20x2
Vacuum system MVS 20/20x2 for production composite parts by vacuum infusion and vacuum bagging technology. The system consists of a high-performance vacuum pump and a resin trap. The system is compatible with epoxy, vinylester and polyester resins. The vacuum trap can be used for degassing the resin.
WORLDWIDE DELIVERY
REQUEST WORLDWIDE DELIVERY
Send Request
Just type your contacts
We will respond to you as soon as possible
Technical specification
MOBILE VACUUM SYSTEM MVS 20/20x2
_
_
Dimensions, LхWхH, mm
1000х500х1000
Connections for vacuum tube, pieces
12
Tube Compatibility
6 pieces – 12 mm
6 pieces – 16 mm
6 pieces – 16 mm
Flow rate, m3/h
20 x2
Resin trap volume, liter
20 x2
Power vacuum pump, kWt
0,6
Pressure, mbar
1
Pump oil volume, liter
0,5
Pump model
VSV-20, Value
Voltage, V
1 phase 220, 50 Hz
Construction
ALUMINIUM
Storage case
+
Tool box
+
