PVC FOAM

CORE MATERIALS
PVC and PVC HT Cross-Linked foam core
Aircell ™ range of foams have been developed to meet the market demands, allowing composite designers and engineers to meet their needs with the most appropriate material.

Aircell ™ is the ideal foam for composite sandwich structures and it is compatible with most resin systems; polyester, vinyl ester, phenolic or epoxy.

Developed for the marine industry, windmills, transport and composite applications in general, Aircell ™ can be supplied in different sheets, with a variety of cut patterns and finishes, either rigid or flexible, to be adapted to different surface shapes. For series production, Aircell ™ can also be supplied in kit form to reduce processing time and wastage.

Aircell ™ is a closed cell, cross-linked polyvinyl chloride foam, with high chemical resistance, great thermal insulation and low water absorption. Its outstanding strength to weight ratio makes it the ideal foam for all composite applications.
REQUEST
RANGE OF AIRCELL® PVC - HR - HTR - HRL
HR STANDARD MAATERIAL
REFERENCE
DENSITY (kg/m3)
SMALL SHEET SIZE (mm)
BIG SHEET SIZE (mm)
THICKNESS RANGE (mm)
HR 40
40
950 x 1330
1330 x 2850
5 - 84
HR 45
45
1270 x 1410
1270 x 2730
5 – 80
HR 60
60
1150 x 1220
1150 x 2450
3 - 78
HR 80
80
1020 x 1080
1020 x 2180
2 - 72
HR 100
100
950 x 1020
950 x 2050
2 - 68
HR 130
130
850 x 925
850 x 1900
2 - 58
HR 160
160
850 x 925
2 - 55
HR 200
200
750 x 800
750 x 1600
2 - 48
HTR HIGH TEMPERATURE
REFERENCE
DENSITY (kg/m3)
SMALL SHEET SIZE (mm)
BIG SHEET SIZE (mm)
THICKNESS RANGE (mm)
HTR 80
80
1000 x 1070
1005 x 2150
2 - 75
HRL RECICLED
REFERENCE
DENSITY (kg/m3)
SMALL SHEET SIZE (mm)
BIG SHEET SIZE (mm)
THICKNESS RANGE (mm)
HRL 60
60
1100 x 1200
1100 x 2400
3 - 72
HRL 80
80
970 x 1070
970 x 2160
2 - 65
AIRCELL® PVC MAIN CHARACTERISTICS
Aircell ™ Is an all-purpose foam core, ideal for all composite sandwich structures; such as hulls, decks, bulkheads, frames and beams, furniture, wind blades and nacelles, civil engineering structures, scaffolding, racing yachts, rail and road transport, subsea applications, sports and leisure, etc.
  • Ideal for all composite sandwich structures
  • Compatible with most resin systems: polyester, vinyl ester, phenolic or epoxy
  • It can be processed at room temperature or at any temperature below 80ºC
  • HTR with high temperature resistance, up to 140ºC (depending on time and pressure)
  • Outstanding strength to weight ratio
  • High chemical resistance
  • Excellent thermal insulation
  • Negligible water absorption
  • DNV & GL approved
  • Thermoformable under heat and pressure
AIRCELL® PVC FINISHING
  • Almost any finish available under request. Tailor made products to improve cost, weight and production
  • Any shape of strips for frames, girders or tapered panel edges
  • Customised CNC machined kits ready to be used
  • Extra thick bonded blocks
PS Plain Sheet
GP1 Infusion Grooved
GS Grit Score
PN Perforated
GP2 Infusion Grooved
GSI Infusion Grit Score
DCI Double Cut
DCL Double Cut - Low Resin Uptake
DCXL Infusion Grit Score - Xtra low Resin Consum
CASE STUDY & TECHNICAL SERVICES MEL Composites
  • 30 mts Passenger Ferries Hull and Deck Infused with internal structure
  • Racing yachts: hull, deck and bulhheads Aircell HR core kit Epoxy and polyester resin infusion
  • 78' – 101 - 111' – 138' Fast Patrol Boats Infused in one shot with internal structure Built to Lloyds Register and DNV-GL
